Plate Compactor


Call for Inquiry

Compacting the ground is a precondition for stability. And it’s best to choose a vibratory plate from Wacker Neuson for compacting different types of ground. With a Plate Compactor from Wacker Neuson Equipments, it doesn’t matter what type of ground it is. Whether mixed soils, paving or asphalt: Wacker Neuson Plate Compactor can compact all common types of ground with the highest level of quality.

Additional information

Operating weight

110 kg

Working width

500 mm

Machine height

620 mm

Working height of handle (adjustable)

838 – 1.093 mm

Base plate thickness

8 mm

Max. centrifugal force

18 kN

Vibration frequency

90 Hz

Forward speed

22 m/min

Max. gradeability (depending on soil)

30 %

Compacted area (depending on soil)

660 m 2/h

Drive engine

air-cooled single cylinder 4-stroke diesel engine

Manufacturer

Hatz

Type

1B20

Max. power output (DIN-ISO 3046*)

3,4 kW

Rated power output

1,4 kW

at

3.520 1/min

Fuel consumption

1,0 l/h

Tank capacity

3 l

Max. allowable tilt of engine in continuous operation

30 °

Power Train

from drive engine via centrifugal clutch and V-belt directly to the Exciter
